ATS & Across Carbon Twin Clutch Kit Spec 2 Getrag Nismo Shaft Light Weight - BNR34
312739
JPY
ATS & ACROSS
SKU: 148707
PN: CN23H260L-14S (12.9kg)This clutch kit is designed for high performance applications. Carbon Discs are much lighter than standard high performance metal type discs reducing overall weight of the clutch kit with great shift feel. Superior material allow for a high friction coefficient disc allowing for longer lasting higher power handling capabilities. Low inertia discs reduce time loss during shifting with quicker synchronization of transmission which also reduces stress on drivetrain components. Available in a variety of different versions and specs to perfectly match any tune and driving preference. Get this and all your JDM at RHDJapan!!
Brand: ATS & Across
Product: Carbon Twin Clutch Kit Spec 2 Getrag Nismo Shaft Light Weight - BNR34
Part Num: CN23H260L-14S (12.9kg)
SPECIFICATIONS:
Cover Type: Push
Clutch Cover Clamping Force (Kg): 1350
Disc Material: Carbon Fiber
Weight: (kg): 12.9
Hub System: Center
Number of Discs: Twin
Hub Spline Teeth Count: 26
Input Shaft (mm): 28.5
PRODUCT NOTES:
Required Parts:
- Clutch Fork: 30531-01S00
- Pivot Spring: 30534-E9000
- Sleeve Spring: 30514L-14600
- Flywheel Bolt: 12315-04U00 X 6pcs (RB30 Crankshaft will require 8pcs)
- Clutch Bearing:
--KOYO: RCT4067L1
--NSK: TK40L-1B2
--NTN: SF0823
- Clutch Sleeve: 30501-02C74
COMPATIBILITY NOTES:
ONLY for 6 Speed Getrag Transmissions with Nismo strengthened shaft.
Product: Carbon Twin Clutch Kit Spec 2 Getrag Nismo Shaft Light Weight - BNR34
Part Num: CN23H260L-14S (12.9kg)
SPECIFICATIONS:
Cover Type: Push
Clutch Cover Clamping Force (Kg): 1350
Disc Material: Carbon Fiber
Weight: (kg): 12.9
Hub System: Center
Number of Discs: Twin
Hub Spline Teeth Count: 26
Input Shaft (mm): 28.5
PRODUCT NOTES:
Required Parts:
- Clutch Fork: 30531-01S00
- Pivot Spring: 30534-E9000
- Sleeve Spring: 30514L-14600
- Flywheel Bolt: 12315-04U00 X 6pcs (RB30 Crankshaft will require 8pcs)
- Clutch Bearing:
--KOYO: RCT4067L1
--NSK: TK40L-1B2
--NTN: SF0823
- Clutch Sleeve: 30501-02C74
COMPATIBILITY NOTES:
ONLY for 6 Speed Getrag Transmissions with Nismo strengthened shaft.
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
Nissan Skyline GT-R BNR34 RB26DETT (01/1999-08/2000)
Nissan Skyline GT-R BNR34 RB26DETT (08/2000-10/2000)
Nissan Skyline GT-R BNR34 RB26DETT (10/2000-08/2002)
Nissan Skyline GT-R BNR34 RB26DETT (01/1999-08/2000)
Nissan Skyline GT-R BNR34 RB26DETT (08/2000-10/2000)
Nissan Skyline GT-R BNR34 RB26DETT (10/2000-08/2002)
