CUSCO Front Sway Stabilizer Bar - Alphard Corolla Estima Harrier Prius Vellfire
34239
JPY
CUSCO
SKU: 87919
PN: 925 311 A30This is also referred to as a stabilizer bar, anti-sway, roll bar or anti-roll bar and it will help decrease body roll and sharpen the handling characteristics of your vehicle whether you have the standard OEM suspension to full coil-over suspension. These are an excellent upgrade for anyone looking to increase handling and increase stability in high speeds. Get this and all your JDM at RHDJapan!!
Brand: CUSCO
Product: Front Sway Stabilizer Bar - Alphard Corolla Estima Harrier Prius Vellfire
Part Num: 925 311 A30
SPECIFICATIONS:
Position: Front
Toyota Alphard/Vellfire ANH20W/GGH20W
Outer Diameter:
- Standard: 26.5
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 135%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 1.0 Hours
Toyota Estima ACR50W/GSR50W/AHR20
Outer Diameter:
- Standard: 26.5
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 135%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 1.0 Hours
Toyota Corolla Rumion ZRE152N
Outer Diameter:
- Standard: 25.4
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 150%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 3.0 Hours
ATH20W:
Outer Diameter:
- Standard: 27
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 135%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 2.5 Hours
ACR50W::
Outer Diameter:
- Standard: 26.5
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 135%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 1.0 Hours
GSR50W::
Outer Diameter:
- Standard: 26.5
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 135%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 2.5 Hours
ACR55W GSR55W::
Outer Diameter:
- Standard: -
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 135%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 2.5 Hours
ZSU60W ZS65W: 2WD 4WD2000cc :
Outer Diameter:
- Standard: 25.4
- Cusco: 30
Adjustable Type: No
Ratio with Standard: (data from 2WD)
- 1st Stage: 150%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 2.5 Hours
AVU65W: 4WD 2500cc Hybrid
Outer Diameter:
- Standard: 25.4
- Cusco: 30
Adjustable Type: No
Ratio with Standard: (data from 2WD)
- 1st Stage: 150%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 2.5 Hours
ZVW40W ZVW41W: 2WD 1800cc
Outer Diameter:
- Standard: 25.4
- Cusco: 30
Adjustable Type: No
Ratio with Standard: (data from 2WD)
- 1st Stage: 150%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 2.5 Hours
Product: Front Sway Stabilizer Bar - Alphard Corolla Estima Harrier Prius Vellfire
Part Num: 925 311 A30
SPECIFICATIONS:
Position: Front
Toyota Alphard/Vellfire ANH20W/GGH20W
Outer Diameter:
- Standard: 26.5
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 135%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 1.0 Hours
Toyota Estima ACR50W/GSR50W/AHR20
Outer Diameter:
- Standard: 26.5
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 135%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 1.0 Hours
Toyota Corolla Rumion ZRE152N
Outer Diameter:
- Standard: 25.4
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 150%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 3.0 Hours
ATH20W:
Outer Diameter:
- Standard: 27
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 135%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 2.5 Hours
ACR50W::
Outer Diameter:
- Standard: 26.5
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 135%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 1.0 Hours
GSR50W::
Outer Diameter:
- Standard: 26.5
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 135%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 2.5 Hours
ACR55W GSR55W::
Outer Diameter:
- Standard: -
- Cusco: 30
Adjustable Type: No
Ratio with Standard:
- 1st Stage: 135%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 2.5 Hours
ZSU60W ZS65W: 2WD 4WD2000cc :
Outer Diameter:
- Standard: 25.4
- Cusco: 30
Adjustable Type: No
Ratio with Standard: (data from 2WD)
- 1st Stage: 150%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 2.5 Hours
AVU65W: 4WD 2500cc Hybrid
Outer Diameter:
- Standard: 25.4
- Cusco: 30
Adjustable Type: No
Ratio with Standard: (data from 2WD)
- 1st Stage: 150%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 2.5 Hours
ZVW40W ZVW41W: 2WD 1800cc
Outer Diameter:
- Standard: 25.4
- Cusco: 30
Adjustable Type: No
Ratio with Standard: (data from 2WD)
- 1st Stage: 150%
- 2nd Stage: -
- 3rd Stage: -
Note: bushing included
Mounting time: 2.5 Hours
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
Toyota Alphard ANH20W 2AZ-FE (05/2008-12/2014)
Toyota Alphard ANH25W 2AZ-FE (05/2008-12/2014)
Toyota Alphard ATH20W 2AZ-FXE (11/2011-01/2015)
Toyota Alphard GGH20W 2GR-FE (05/2008-12/2014)
Toyota Alphard GGH25W 2GR-FE (05/2008-12/2014)
Toyota Corolla Rumion ZRE152N 2ZR-FE (10/2007-12/2015)
Toyota Estima ACR50W 2AZ-FE (01/2006-12/2008)
Toyota Estima ACR50W 2AZ-FE (12/2008-05/2016)
Toyota Estima ACR55W 2AZ-FE (01/2006-12/2008)
Toyota Estima ACR55W 2AZ-FE (12/2008-05/2016)
Toyota Estima AHR20W 2AZ-FXE (01/2006-12/2008)
Toyota Estima AHR20W 2AZ-FXE (12/2008-05/2016)
Toyota Estima GSR50W 2GR-FE (01/2006-12/2008)
Toyota Estima GSR50W 2GR-FE (12/2008-05/2016)
Toyota Estima GSR55W 2GR-FE (01/2006-12/2008)
Toyota Estima GSR55W 2GR-FE (12/2008-05/2016)
Toyota Harrier AVU65W 2AR-FXE (01/2014-06/2017)
Toyota Harrier ZSU60W 3ZR-FAE (12/2013-04/2017)
Toyota Harrier ZSU65W 3ZR-FAE (12/2013-04/2017)
Toyota Prius α ZVW40W 2ZR-FXE (05/2011-10/2014)
Toyota Prius α ZVW41W 2ZR-FXE (05/2011-10/2014)
Toyota Vellfire ANH20W 2AZ-FE (05/2008-12/2014)
Toyota Vellfire ANH25W 2AZ-FE (05/2008-12/2014)
Toyota Vellfire GGH20W 2GR-FE (05/2008-12/2014)
Toyota Vellfire GGH25W 2GR-FE (05/2008-12/2014)
Toyota Alphard ANH20W 2AZ-FE (05/2008-12/2014)
Toyota Alphard ANH25W 2AZ-FE (05/2008-12/2014)
Toyota Alphard ATH20W 2AZ-FXE (11/2011-01/2015)
Toyota Alphard GGH20W 2GR-FE (05/2008-12/2014)
Toyota Alphard GGH25W 2GR-FE (05/2008-12/2014)
Toyota Corolla Rumion ZRE152N 2ZR-FE (10/2007-12/2015)
Toyota Estima ACR50W 2AZ-FE (01/2006-12/2008)
Toyota Estima ACR50W 2AZ-FE (12/2008-05/2016)
Toyota Estima ACR55W 2AZ-FE (01/2006-12/2008)
Toyota Estima ACR55W 2AZ-FE (12/2008-05/2016)
Toyota Estima AHR20W 2AZ-FXE (01/2006-12/2008)
Toyota Estima AHR20W 2AZ-FXE (12/2008-05/2016)
Toyota Estima GSR50W 2GR-FE (01/2006-12/2008)
Toyota Estima GSR50W 2GR-FE (12/2008-05/2016)
Toyota Estima GSR55W 2GR-FE (01/2006-12/2008)
Toyota Estima GSR55W 2GR-FE (12/2008-05/2016)
Toyota Harrier AVU65W 2AR-FXE (01/2014-06/2017)
Toyota Harrier ZSU60W 3ZR-FAE (12/2013-04/2017)
Toyota Harrier ZSU65W 3ZR-FAE (12/2013-04/2017)
Toyota Prius α ZVW40W 2ZR-FXE (05/2011-10/2014)
Toyota Prius α ZVW41W 2ZR-FXE (05/2011-10/2014)
Toyota Vellfire ANH20W 2AZ-FE (05/2008-12/2014)
Toyota Vellfire ANH25W 2AZ-FE (05/2008-12/2014)
Toyota Vellfire GGH20W 2GR-FE (05/2008-12/2014)
Toyota Vellfire GGH25W 2GR-FE (05/2008-12/2014)
