Fujitsubo A-R Exhaust Muffler System - BRZ ZD8 GR86 ZN8
113449
JPY
FUJITSUBO
SKU: 286960
PN: 560-23212A great sports sound and quality performance were the priorities in developing this lineup of mufflers. The high quality construction and enhanced diameter allows for great exhaust flow improving torque and power throughout the whole power band, especially the mid to high RPM zone. Classic visual styling designed to provide a high quality aggressive engine sound, light weight and all around performance. Get this and all your JDM at RHDJapan!!
Brand: Fujitsubo
Product: A-R Exhaust Muffler System - BRZ ZD8 GR86 ZN8
Part Number: 560-23212
SPECIFICATIONS
Series: A-R (previously Authorize R)
Material: Stainless Steel (SUS304)
Tip Type: Slash
Tip Diameter (mm): 101.6
Pipe Diameter (mm): 65-50.8
Muffler Weight (kg):
- OEM: 16.4
- Fujitsubo: 16.4
Intermediate acceleration (50km/h to 100km/h in M2 gear) (seconds):
- OEM: 2.4
- Fujitsubo: 2.4
Maximum output
- OEM: 164.3kw(223.4ps)/6910rpm
- Fujitsubo: 168.4kw(229.0ps)/6920rpm
Maximum torque
- OEM: 236.2N･m(24.1kg･m)/3160rpm
- Fujitsubo: 242.1N･m(24.7kg･m)/3210rpm
Noise Levels (dB):
OEM:
- Idling Sound: 56
- Noise Near exhaust (5250rpm): 83
- 3000rpm: 71
- 5000rpm: 81
- Response 4000rpm~6000rpm: 93
Fujitsubo:
- Idling Sound: 68
- Noise Near exhaust (5250rpm): 92
- 3000rpm: 88
- 5000rpm: 85
- Response 4000rpm~6000rpm: 101
Included Items
- Authorize R Exhaust Muffler
- Gasket Packing X2
- Ring Gasket X1
- M10X20 Flange Bolt & Nut Set X2
- M10X35 Bolt SW Nut Set X4
COMPATIBILITY NOTES:
-Manual Transmission only
Product: A-R Exhaust Muffler System - BRZ ZD8 GR86 ZN8
Part Number: 560-23212
SPECIFICATIONS
Series: A-R (previously Authorize R)
Material: Stainless Steel (SUS304)
Tip Type: Slash
Tip Diameter (mm): 101.6
Pipe Diameter (mm): 65-50.8
Muffler Weight (kg):
- OEM: 16.4
- Fujitsubo: 16.4
Intermediate acceleration (50km/h to 100km/h in M2 gear) (seconds):
- OEM: 2.4
- Fujitsubo: 2.4
Maximum output
- OEM: 164.3kw(223.4ps)/6910rpm
- Fujitsubo: 168.4kw(229.0ps)/6920rpm
Maximum torque
- OEM: 236.2N･m(24.1kg･m)/3160rpm
- Fujitsubo: 242.1N･m(24.7kg･m)/3210rpm
Noise Levels (dB):
OEM:
- Idling Sound: 56
- Noise Near exhaust (5250rpm): 83
- 3000rpm: 71
- 5000rpm: 81
- Response 4000rpm~6000rpm: 93
Fujitsubo:
- Idling Sound: 68
- Noise Near exhaust (5250rpm): 92
- 3000rpm: 88
- 5000rpm: 85
- Response 4000rpm~6000rpm: 101
Included Items
- Authorize R Exhaust Muffler
- Gasket Packing X2
- Ring Gasket X1
- M10X20 Flange Bolt & Nut Set X2
- M10X35 Bolt SW Nut Set X4
COMPATIBILITY NOTES:
-Manual Transmission only
Compatibility is from maker for JDM cars only.
We don't guarantee fitment.
Always do your own research before purchase.
Subaru BRZ ZD8 FA24 (08/2021~)
Toyota GR86 ZN8 FA24 (10/2021~)
Subaru BRZ ZD8 FA24 (08/2021~)
Toyota GR86 ZN8 FA24 (10/2021~)
