HKS V Cam System Step 1 without VALCON - BNR32 BCNR33 BNR34
326169
JPY
HKS
SKU: 292303
PN: 22007-AN020This kit is based off of the V Cam System now available for a lower price without the VALCON (Valve Timing Controller) electronics. With the fine tuning of valve timing this item will help to unleash massive amounts of torque, response and power all throughout the power band. Available in three different steps to best match different tuning levels. Get this and all your JDM at RHDJapan!!
Brand: HKS
Product: V Cam System - Step 1
Part Number: 22007-AN020
SPECIFICATIONS:
Version: Step 1
Intake Camshaft Duration (°): 248
Valve Lift (mm): 8.6
Adjustable Valve Timing Range (°): 90 ~ 120
Intake Valve Cover Color: Unpainted
Electromagnetic Oil Control Valve Included
HKS Oil Filler Cap Included
High Precision Cam Angle Sensor Included
Misc. small parts included
PRODUCT NOTES:
Additional Items Necessary For Installation (Sold Separately): Exhaust Camshaft
- Valves and pistons may not clear when V Cam System is used in conjunction with thin head gasket or modified cylinder head.
- Exhaust Camshaft (Sold Separately) should be chosen depending on turbo choice. (Recommendations: GT-SS = 256 degree, GT2530 = 264 degree)
- Vehicle Specific F-CON Harness Sold Separately
- Maximum RPM for Step 1: 8, 000RPM (OEM Rev Limiter)
- Oil pressure cannot be maintained at a safe operating pressure when oil viscosity is low. Valve timing may not reach desired figures due to this.
- Camshaft will not advance is water temperature is below 20 degrees Celsius
- Recommended Engine Oil: Super Oil (RB), Racing Oil 10W-50
- Tension and wear of Timing Belt must be checked every 10, 000km
Product: V Cam System - Step 1
Part Number: 22007-AN020
SPECIFICATIONS:
Version: Step 1
Intake Camshaft Duration (°): 248
Valve Lift (mm): 8.6
Adjustable Valve Timing Range (°): 90 ~ 120
Intake Valve Cover Color: Unpainted
Electromagnetic Oil Control Valve Included
HKS Oil Filler Cap Included
High Precision Cam Angle Sensor Included
Misc. small parts included
PRODUCT NOTES:
Additional Items Necessary For Installation (Sold Separately): Exhaust Camshaft
- Valves and pistons may not clear when V Cam System is used in conjunction with thin head gasket or modified cylinder head.
- Exhaust Camshaft (Sold Separately) should be chosen depending on turbo choice. (Recommendations: GT-SS = 256 degree, GT2530 = 264 degree)
- Vehicle Specific F-CON Harness Sold Separately
- Maximum RPM for Step 1: 8, 000RPM (OEM Rev Limiter)
- Oil pressure cannot be maintained at a safe operating pressure when oil viscosity is low. Valve timing may not reach desired figures due to this.
- Camshaft will not advance is water temperature is below 20 degrees Celsius
- Recommended Engine Oil: Super Oil (RB), Racing Oil 10W-50
- Tension and wear of Timing Belt must be checked every 10, 000km
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
Nissan Skyline GT-R BCNR33 RB26DETT (01/1995-01/1996)
Nissan Skyline GT-R BCNR33 RB26DETT (01/1996-02/1997)
Nissan Skyline GT-R BCNR33 RB26DETT (02/1997-05/1998)
Nissan Skyline GT-R BNR32 RB26DETT (08/1989-08/1991)
Nissan Skyline GT-R BNR32 RB26DETT (08/1991-02/1993)
Nissan Skyline GT-R BNR32 RB26DETT (02/1993-12/1994)
Nissan Skyline GT-R BNR34 RB26DETT (01/1999-08/2000)
Nissan Skyline GT-R BNR34 RB26DETT (08/2000-10/2000)
Nissan Skyline GT-R BNR34 RB26DETT (10/2000-08/2002)
Nissan Skyline GT-R BCNR33 RB26DETT (01/1995-01/1996)
Nissan Skyline GT-R BCNR33 RB26DETT (01/1996-02/1997)
Nissan Skyline GT-R BCNR33 RB26DETT (02/1997-05/1998)
Nissan Skyline GT-R BNR32 RB26DETT (08/1989-08/1991)
Nissan Skyline GT-R BNR32 RB26DETT (08/1991-02/1993)
Nissan Skyline GT-R BNR32 RB26DETT (02/1993-12/1994)
Nissan Skyline GT-R BNR34 RB26DETT (01/1999-08/2000)
Nissan Skyline GT-R BNR34 RB26DETT (08/2000-10/2000)
Nissan Skyline GT-R BNR34 RB26DETT (10/2000-08/2002)
