Kakimoto Racing HYPER FULLMEGA N1+ Rev. Muffler Exhaust System - NB6C NB8C NB8C#
64709
JPY
KAKIMOTO RACING
SKU: 288718
PN: Z31304This exhaust system has been developed as a high spec all around muffler. Developed to push the JASMA max limits to still be used on the street while also providing great performance and race sport sound. Full high-grade stainless construction with compact silencer and original design flange and stays for the great balance of weight, strength and durability. Get this and all your JDM at RHDJapan!!
Brand: Kakimoto Racing
Product: HYPER FULLMEGA N1+ Rev. Muffler Exhaust System - NB6C NB8C NB8C#
Part Number: Z31304
SPECIFICATIONS:
Series: HYPER FULLMEGA N1+ Rev.
Material: Stainless Steel (SUS304)
Main Pipe Diameter (mm): 60
Main Silencer Diameter (mm): 127
Tail Diameter (mm): 100
Muffler Outlet: Single - Right
Piece Construction: 1
JAN Code: 4512355175839
JQR/JASMA Code: 03S08247
PRODUCT NOTES:
- Noise Level Output (dB) for NB6C B6-ZE (01/98~08/05):
-Maximum: 92
-At Idle: N/A
- Noise Level Output (dB) for NB8C BP-ZE, BP-VE (01/98~08/05):
-Maximum: 92
-At Idle: 61
- Noise Level Output (dB) for NB8C# BP-VE (10/03~08/05):
-Maximum: 89
-At Idle: 63
- Weight (kg):
-Kakimoto: 8.5
-OEM NB6C B6-ZE (01/98~08/05): 9.5
- Weight (kg):
-Kakimoto: 8.5
-OEM NB8C BP-ZE, BP-VE (01/98~08/05): 9.5
- Weight (kg):
-Kakimoto: 8.5
-OEM NB8C# BP-VE (10/03~08/05): 9.5
- Rear Piece only
COMPATIBILITY NOTES:
- Roadster Coupe NB8C# BP-VE 10/2003~08/2005: TypeS, TypeE, TypeA 1.8 NA BP-VE 2WD(FR) 6MT/4AT
- Roadster NB6C B6-ZE 01/1998~08/2005: M, NR-A, SP, M package, special package, standard car 1.6 NA B6-ZE 2WD(FR) 5MT/4AT
- Roadster NB8C BP-ZE, BP-VE 01/1998~08/2005: BP-VE engine vehicles are not JASMA certified.
- Roadster NB8C BP-ZE, BP-VE 01/1998~08/2005: S,RS(ⅡIncluded), VS(CombinationA, CombinationB Included) 1.8 NA BP-ZE, BP-VE 2WD(FR) 6MT/4AT
Product: HYPER FULLMEGA N1+ Rev. Muffler Exhaust System - NB6C NB8C NB8C#
Part Number: Z31304
SPECIFICATIONS:
Series: HYPER FULLMEGA N1+ Rev.
Material: Stainless Steel (SUS304)
Main Pipe Diameter (mm): 60
Main Silencer Diameter (mm): 127
Tail Diameter (mm): 100
Muffler Outlet: Single - Right
Piece Construction: 1
JAN Code: 4512355175839
JQR/JASMA Code: 03S08247
PRODUCT NOTES:
- Noise Level Output (dB) for NB6C B6-ZE (01/98~08/05):
-Maximum: 92
-At Idle: N/A
- Noise Level Output (dB) for NB8C BP-ZE, BP-VE (01/98~08/05):
-Maximum: 92
-At Idle: 61
- Noise Level Output (dB) for NB8C# BP-VE (10/03~08/05):
-Maximum: 89
-At Idle: 63
- Weight (kg):
-Kakimoto: 8.5
-OEM NB6C B6-ZE (01/98~08/05): 9.5
- Weight (kg):
-Kakimoto: 8.5
-OEM NB8C BP-ZE, BP-VE (01/98~08/05): 9.5
- Weight (kg):
-Kakimoto: 8.5
-OEM NB8C# BP-VE (10/03~08/05): 9.5
- Rear Piece only
COMPATIBILITY NOTES:
- Roadster Coupe NB8C# BP-VE 10/2003~08/2005: TypeS, TypeE, TypeA 1.8 NA BP-VE 2WD(FR) 6MT/4AT
- Roadster NB6C B6-ZE 01/1998~08/2005: M, NR-A, SP, M package, special package, standard car 1.6 NA B6-ZE 2WD(FR) 5MT/4AT
- Roadster NB8C BP-ZE, BP-VE 01/1998~08/2005: BP-VE engine vehicles are not JASMA certified.
- Roadster NB8C BP-ZE, BP-VE 01/1998~08/2005: S,RS(ⅡIncluded), VS(CombinationA, CombinationB Included) 1.8 NA BP-ZE, BP-VE 2WD(FR) 6MT/4AT
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
Mazda Roadster NB6C B6-ZE (01/1998-07/2000)
Mazda Roadster NB6C B6-ZE (08/2000-07/2005)
Mazda Roadster NB8C BP-VE (08/2000-07/2005)
Mazda Roadster NB8C BP-ZE (01/1998-07/2000)
Mazda Roadster NB8C BP-ZE (08/2000-07/2005)
Mazda Roadster NB6C B6-ZE (01/1998-07/2000)
Mazda Roadster NB6C B6-ZE (08/2000-07/2005)
Mazda Roadster NB8C BP-VE (08/2000-07/2005)
Mazda Roadster NB8C BP-ZE (01/1998-07/2000)
Mazda Roadster NB8C BP-ZE (08/2000-07/2005)
