Kinokuni Oil Thermo Block Oil Filter Relocation with Sensor Adapter - UNF3/4-16 Center Bolt AN12 Fittings
18869
JPY
KINOKUNI
SKU: 167030
PN: K600-34-12This item is designed for the relocation of the engine oil filter from the engine to a more desired location in the engine bay. In addition it has built in thermostat and upgraded fittings for improving engine cooling performance. Service Holes made for fittings for most standard oil temperature or pressure sensors. Available with a variety of different fitting options for the oil lines. A recommended step up when reinforcing or upgrading the very important cooling system. Get this and all your JDM at RHDJapan!!
Brand: Kinokuni
Product: Oil Thermo Block Oil Filter Relocation with Sensor Adapter - UNF3/4-16 Center Bolt AN12 Fittings
Part Number: K600-34-12
SPECIFICATIONS:
Center Bolt Size: UNF3/4"-16
Thermostat:
-Open Start (℃): 73
-Open Max (℃): 85
Fitting Size (AN): 12
O-Ring Size: Double
Included:
-K600 Block X 1pc
-O-Ring Seal X1pc
-AN12 Male Fittings X 4pcs
-Sensor Fitting for Oil Temperature or Oil Pressure X 3 Service Hole (M8×1.25P)
-Thermostat X1pcs
-Center Bolt X 1pc
COMPATIBILITY NOTES:
- When used with K300 series engine side adapter block the items can be run to compatible sized oil cooler lines for Oil Killer Core.
Oil Filter with 65mm or 70mm diameter O-Ring
Toyota based oil filters using UNF3/4"-16 center bolt
Product: Oil Thermo Block Oil Filter Relocation with Sensor Adapter - UNF3/4-16 Center Bolt AN12 Fittings
Part Number: K600-34-12
SPECIFICATIONS:
Center Bolt Size: UNF3/4"-16
Thermostat:
-Open Start (℃): 73
-Open Max (℃): 85
Fitting Size (AN): 12
O-Ring Size: Double
Included:
-K600 Block X 1pc
-O-Ring Seal X1pc
-AN12 Male Fittings X 4pcs
-Sensor Fitting for Oil Temperature or Oil Pressure X 3 Service Hole (M8×1.25P)
-Thermostat X1pcs
-Center Bolt X 1pc
COMPATIBILITY NOTES:
- When used with K300 series engine side adapter block the items can be run to compatible sized oil cooler lines for Oil Killer Core.
Oil Filter with 65mm or 70mm diameter O-Ring
Toyota based oil filters using UNF3/4"-16 center bolt
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
