Power Enterprise Fuel Injector 380cc Z33 ER34 V35

Brand: Power Enterprise
Product: Fuel Injector 380cc
Part Number: TH380NZ_159713

FEATURES:
PWR injectors support high power and high response together
Many of fuel system of the engine are electrically controlled. Multi Point Injection (MPI) system is that injectors are installed in each cylinder. Power Enterprise offer two kinds of a injector, top feed and side feed (bottom feed) (cf. fig. 1). The number of injector nozzles is divided into one and two by the specification of the engine. DOHC 4 valve engine has two intake ports and often takes two injector nozzles. The reason is to avoid incomplete combustion caused by fuel mist hit and crushed on the wall of a intake port and flowing in drops. The injector basically sprays fuel (150-200 microns) on the back of a valve head preventing fuel mist from hitting against the wall of a intake port (cf. fig. 2). The injector capacity becomes larger and larger, the bad influence of this problem is increased. Power Enterprise designed and developed injectors for RB26 (normal one has one intake port.), 1JZ and 2JZ. PWR big capacity injectors realize not only high power output but also improvement of the response and cleaning exhaust gas.

SPECIFICATIONS: WHOLE BRAND REMOVED FROM WEBSITE ON PURPOSE
Item name: TH380NZ
Resistance: High
Nozzle: 12
Connector: Oval
Connector Color: Light Blue
Flow: 380cc
Lagtime: 0.85
