Toda Racing Inner Shim Conversion Kit Std Lift - NA8C NB8C
68219
JPY
TODA RACING
SKU: 51800
PN: 14730-BP0-000This will reduces inertia and friction allowing the engine to rev higher by removing weight from the moving parts of the valve train. Get this and all your JDM at RHDJapan!!
Brand: Toda Racing
Product: Inner Shim Conversion Kit Std Lift - NA8C NB8C
Part Num: 14730-BP0-000
SPECIFICATIONS:
Standard Lift (mm):
Type: 36 (Standard base circle diameter)
Cam lift: Toda 9mm
PRODUCT NOTES:
- The lifter is the only part to be replaced.
- Stock valve spring can be used.
- Common part for both NA8 & NB8 engines.
- Standard HLA lifter Normally Aspirated and normal outer shim lifter (NB) should be replaced with Toda's Inner-Shim Conversion KIT. Reductions in mass and friction are found. The standard spring retainer, valve spring and spring seat can be used.
- The kit contains standard size shims, but on occasion other size shims will be required to create the required gap, these are sold separately.
FEATURES:
Since NA8C BP NA8C uses HLA's as standard. For tuning purposes these heavy hydraulic lash adjusters that have a tendency to leak becoming a big bottle neck in extracting performance from high lift cams. Replacing them with Toda's Inner-Shim Conversion KIT not only reduces the weight by 17.5g per lifter but removes oil pressure fluctuations, enabling the engine to reach higher engine speeds safely.
Since NB8C BP NB8C uses an outer shim type lifter. Due to the smaller tappet face (shim diameter) the contact area with the cam is reduced making it dangerous to use high lift cams. Replacing them with Toda's Inner-Shim Conversion KIT not only gives you the contact area required but also reduces the weight by 9g per lifter again freeing up the engine giving you more power.
Product: Inner Shim Conversion Kit Std Lift - NA8C NB8C
Part Num: 14730-BP0-000
SPECIFICATIONS:
Standard Lift (mm):
Type: 36 (Standard base circle diameter)
Cam lift: Toda 9mm
PRODUCT NOTES:
- The lifter is the only part to be replaced.
- Stock valve spring can be used.
- Common part for both NA8 & NB8 engines.
- Standard HLA lifter Normally Aspirated and normal outer shim lifter (NB) should be replaced with Toda's Inner-Shim Conversion KIT. Reductions in mass and friction are found. The standard spring retainer, valve spring and spring seat can be used.
- The kit contains standard size shims, but on occasion other size shims will be required to create the required gap, these are sold separately.
FEATURES:
Since NA8C BP NA8C uses HLA's as standard. For tuning purposes these heavy hydraulic lash adjusters that have a tendency to leak becoming a big bottle neck in extracting performance from high lift cams. Replacing them with Toda's Inner-Shim Conversion KIT not only reduces the weight by 17.5g per lifter but removes oil pressure fluctuations, enabling the engine to reach higher engine speeds safely.
Since NB8C BP NB8C uses an outer shim type lifter. Due to the smaller tappet face (shim diameter) the contact area with the cam is reduced making it dangerous to use high lift cams. Replacing them with Toda's Inner-Shim Conversion KIT not only gives you the contact area required but also reduces the weight by 9g per lifter again freeing up the engine giving you more power.
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
Mazda Roadster NA8C BP (09/1993-07/1995)
Mazda Roadster NA8C BP (08/1995-12/1997)
Mazda Roadster NB8C BP-ZE (01/1998-07/2000)
Mazda Roadster NB8C BP-ZE (08/2000-07/2005)
Mazda Roadster NA8C BP (09/1993-07/1995)
Mazda Roadster NA8C BP (08/1995-12/1997)
Mazda Roadster NB8C BP-ZE (01/1998-07/2000)
Mazda Roadster NB8C BP-ZE (08/2000-07/2005)
