Tomei Competition Bearing Main Inner Lower Grade D - RB26DETT RB25DE(T)
1650
JPY
TOMEI
SKU: 101696
PN: 1231N1201DThereare designed for fatigue resistance, durability, effective lubrication and resistance to scoring. These are a must when rebuilding your engine! With these installed you can rest assured that your racing investment will be in good hands, Tomei hands! Dont accept anything less than the best!
The price is for one(1) piece (6 are needed). Please add as many as you need to the shopping cart.
Get this and all your JDM at RHDJapan!!
The price is for one(1) piece (6 are needed). Please add as many as you need to the shopping cart.
Get this and all your JDM at RHDJapan!!
Brand: Tomei
Product: Competition Bearing Main Inner Lower Grade D - RB26DETT RB25DE(T)
Part Num: 1231N1201D
SPECIFICATIONS:
Grade D:
- OEM Grade: 3
- Size: 1.827-1.830
- Grade Color: Red
COMPATIBILITY NOTES:
- Only For Nissan Skyline.
FEATURES:
Durability & Reliability, The Answer for All Professionals!!
When tuning engines for higher power output and high RPM the bearings are subjected to extreme load conditions. These harsh conditions require the bearings to be able to cope with excessive loads and stress conditions. The Tomei Competition Bearing series are designed for fatigue resistance, durability, effective lubrication and resistance to scoring. Designed for use on engines that will be outputting 1, 000 HP and at over 10, 000RPM. These advanced designed bearings are suitable for the serious professionals in mind whom need results. We also have 3 grades available on all engine applications.
Materials:
- The P76 material is used for it's superior abrasion and fatigue resistance. The elimination of the tin flash plating improves the heat transfer through the bearing.
- The F781 material is used on connecting rod bearings for high performance engines. It has a hardened steel backing to improve the support of the bearing lining and assist bearing retention in the housing.
- The combination of these material enhancements optimize bearing performance under high loads and temperatures.
Crush:
- The Competition Bearing Series are designed with an increased crush (i.e. extra bearing length of typically 0.100-0.175mm). The extra crush improves the retention of the bearing in it's housing.- Crush Height: The crush height is based on the bearing being a fraction longer than the housing seating so that a small section protrudes above the rod bore parting surface. When the rod halves are drawn together, the inserts touch before the halves, thus forcing the inserts tightly into place.Eccentricity:
The wall thickness at the crown of the shell is thicker than the wall at 3/8 down from the parting face. These Competition Bearing Series have an increased amount of eccentricity to compensate for the bearing housing bore elongation in extreme conditions and to help create an effective hydrodynamic oil film.
Locating Tangs (Notches):
The Notches help with bearing alignment during fitment. They do not hold the bearings in place during operation, that is the function of Crush.
Bored Surface:
The bore bearing surface finish method helps promote effective oil flow and to maintain adequate lubrication for both the bearings and other moving parts.
Oil Grooves:
The design of the oil grooves on the lower main bearing shell is always a trade off between oil supply to the Conrods and the bearings load carrying capacity. The Tomei Competition Bearings generally have a 3/4 groove to give optimum balance of oil flow whilst keeping optimum load carrying capacity.
Product: Competition Bearing Main Inner Lower Grade D - RB26DETT RB25DE(T)
Part Num: 1231N1201D
SPECIFICATIONS:
Grade D:
- OEM Grade: 3
- Size: 1.827-1.830
- Grade Color: Red
COMPATIBILITY NOTES:
- Only For Nissan Skyline.
FEATURES:
Durability & Reliability, The Answer for All Professionals!!
When tuning engines for higher power output and high RPM the bearings are subjected to extreme load conditions. These harsh conditions require the bearings to be able to cope with excessive loads and stress conditions. The Tomei Competition Bearing series are designed for fatigue resistance, durability, effective lubrication and resistance to scoring. Designed for use on engines that will be outputting 1, 000 HP and at over 10, 000RPM. These advanced designed bearings are suitable for the serious professionals in mind whom need results. We also have 3 grades available on all engine applications.
Materials:
- The P76 material is used for it's superior abrasion and fatigue resistance. The elimination of the tin flash plating improves the heat transfer through the bearing.
- The F781 material is used on connecting rod bearings for high performance engines. It has a hardened steel backing to improve the support of the bearing lining and assist bearing retention in the housing.
- The combination of these material enhancements optimize bearing performance under high loads and temperatures.
Crush:
- The Competition Bearing Series are designed with an increased crush (i.e. extra bearing length of typically 0.100-0.175mm). The extra crush improves the retention of the bearing in it's housing.- Crush Height: The crush height is based on the bearing being a fraction longer than the housing seating so that a small section protrudes above the rod bore parting surface. When the rod halves are drawn together, the inserts touch before the halves, thus forcing the inserts tightly into place.Eccentricity:
The wall thickness at the crown of the shell is thicker than the wall at 3/8 down from the parting face. These Competition Bearing Series have an increased amount of eccentricity to compensate for the bearing housing bore elongation in extreme conditions and to help create an effective hydrodynamic oil film.
Locating Tangs (Notches):
The Notches help with bearing alignment during fitment. They do not hold the bearings in place during operation, that is the function of Crush.
Bored Surface:
The bore bearing surface finish method helps promote effective oil flow and to maintain adequate lubrication for both the bearings and other moving parts.
Oil Grooves:
The design of the oil grooves on the lower main bearing shell is always a trade off between oil supply to the Conrods and the bearings load carrying capacity. The Tomei Competition Bearings generally have a 3/4 groove to give optimum balance of oil flow whilst keeping optimum load carrying capacity.
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
Nissan Skyline ECR32 RB25DE (08/1991-08/1993)
Nissan Skyline ECR33 RB25DET (01/1995-01/1996)
Nissan Skyline ECR33 RB25DET (01/1996-05/1998)
Nissan Skyline ECR33 RB25DET (08/1993-01/1995)
Nissan Skyline ENR33 RB25DE (01/1995-01/1996)
Nissan Skyline ENR33 RB25DE (01/1996-05/1998)
Nissan Skyline ENR33 RB25DE (08/1993-01/1995)
Nissan Skyline ENR34 RB25DE (05/1998-08/2000)
Nissan Skyline ENR34 RB25DE (08/2000-06/2001)
Nissan Skyline ER32 RB25DE (08/1991-08/1993)
Nissan Skyline ER33 RB25DE (01/1995-01/1996)
Nissan Skyline ER33 RB25DE (01/1996-05/1998)
Nissan Skyline ER33 RB25DE (08/1993-01/1995)
Nissan Skyline ER34 RB25DE (05/1998-08/2000)
Nissan Skyline ER34 RB25DE (08/2000-06/2001)
Nissan Skyline ER34 RB25DET (05/1998-08/2000)
Nissan Skyline ER34 RB25DET (08/2000-06/2001)
Nissan Skyline GT-R BCNR33 RB26DETT (01/1995-01/1996)
Nissan Skyline GT-R BCNR33 RB26DETT (01/1996-02/1997)
Nissan Skyline GT-R BCNR33 RB26DETT (02/1997-05/1998)
Nissan Skyline GT-R BNR32 RB26DETT (02/1993-12/1994)
Nissan Skyline GT-R BNR32 RB26DETT (08/1989-08/1991)
Nissan Skyline GT-R BNR32 RB26DETT (08/1991-02/1993)
Nissan Skyline GT-R BNR34 RB26DETT (01/1999-08/2000)
Nissan Skyline GT-R BNR34 RB26DETT (08/2000-10/2000)
Nissan Skyline GT-R BNR34 RB26DETT (10/2000-08/2002)
Nissan Skyline ECR32 RB25DE (08/1991-08/1993)
Nissan Skyline ECR33 RB25DET (01/1995-01/1996)
Nissan Skyline ECR33 RB25DET (01/1996-05/1998)
Nissan Skyline ECR33 RB25DET (08/1993-01/1995)
Nissan Skyline ENR33 RB25DE (01/1995-01/1996)
Nissan Skyline ENR33 RB25DE (01/1996-05/1998)
Nissan Skyline ENR33 RB25DE (08/1993-01/1995)
Nissan Skyline ENR34 RB25DE (05/1998-08/2000)
Nissan Skyline ENR34 RB25DE (08/2000-06/2001)
Nissan Skyline ER32 RB25DE (08/1991-08/1993)
Nissan Skyline ER33 RB25DE (01/1995-01/1996)
Nissan Skyline ER33 RB25DE (01/1996-05/1998)
Nissan Skyline ER33 RB25DE (08/1993-01/1995)
Nissan Skyline ER34 RB25DE (05/1998-08/2000)
Nissan Skyline ER34 RB25DE (08/2000-06/2001)
Nissan Skyline ER34 RB25DET (05/1998-08/2000)
Nissan Skyline ER34 RB25DET (08/2000-06/2001)
Nissan Skyline GT-R BCNR33 RB26DETT (01/1995-01/1996)
Nissan Skyline GT-R BCNR33 RB26DETT (01/1996-02/1997)
Nissan Skyline GT-R BCNR33 RB26DETT (02/1997-05/1998)
Nissan Skyline GT-R BNR32 RB26DETT (02/1993-12/1994)
Nissan Skyline GT-R BNR32 RB26DETT (08/1989-08/1991)
Nissan Skyline GT-R BNR32 RB26DETT (08/1991-02/1993)
Nissan Skyline GT-R BNR34 RB26DETT (01/1999-08/2000)
Nissan Skyline GT-R BNR34 RB26DETT (08/2000-10/2000)
Nissan Skyline GT-R BNR34 RB26DETT (10/2000-08/2002)
