Tomei Technical Trax Advance 2 Way LSD with LSD Oil Type TFA - Altezza SXE10 GXE10 JZX90 JZX100 JZX105
111929
JPY
TOMEI
SKU: 146276
PN: 562043This is the most effective LSD unit available and has the best overall advantage in comparison with the other aftermarket products available today. Amazing penetrating angles at the time of Drift, with such persistence in the accuracy of line taking and all aspects of cornering, the T-TRAX ADVANCE shows amazing efficiency with the aggressive cam angles which is optimum for drifting. The friction clutch discs also have a larger surface area and, with the use of the coil spring discs and the high setting of initial torque, it is raised higher than any other brands in the market today.
Get this and all your JDM at RHDJapan!!
Get this and all your JDM at RHDJapan!!
Brand: Tomei
Product: Technical Trax Advance 2 Way LSD with LSD Oil - Altezza SXE10 GXE10 JZX90 JZX100 JZX105
Part Num: 562043
SPECIFICATIONS:
Type: TFA
The kit Contains:
- T-Trax Advance 2 way LSD
- 2L Low Friction High Grade Oil
PCD: 140
Disc:
- Ext Dia.: 93
- No. (In Dia.): 8
- No. (Ex Dia.): 8
- Thickness: 1.7
Spring:
- No. Ex Teeth: N/A
- No. In Teeth: N/A
- No. Teeth N/A: 2
- No. Teeth N/A Strengthening: N/A
Size & No. of Ring Gear Bolts: 8-11.3
No. of Serration Teeth: 27T
Flange In Dia.: 35.0
Initial Torque Pre Setting (kg.m): 12.5~15.5
Super High Initial: X
Pressure Ring Cam Angle: 6060
COMPATIBILITY NOTES:
- Altezza SXE10, GXE10 with Open/Torsen type LSD.
- Mark II/Chaser/Cresta JZX90 with Open type LSD. Only AT vehicles with 1G-GE Engine.
- Mark II/Chaser/Cresta JZX100 (1JZ-GE) AT before 8/97 with Open type LSD. Tourer S Grade excluded
- Mark II/Chaser/Cresta JZX105 AT with Open type LSD.
Product: Technical Trax Advance 2 Way LSD with LSD Oil - Altezza SXE10 GXE10 JZX90 JZX100 JZX105
Part Num: 562043
SPECIFICATIONS:
Type: TFA
The kit Contains:
- T-Trax Advance 2 way LSD
- 2L Low Friction High Grade Oil
PCD: 140
Disc:
- Ext Dia.: 93
- No. (In Dia.): 8
- No. (Ex Dia.): 8
- Thickness: 1.7
Spring:
- No. Ex Teeth: N/A
- No. In Teeth: N/A
- No. Teeth N/A: 2
- No. Teeth N/A Strengthening: N/A
Size & No. of Ring Gear Bolts: 8-11.3
No. of Serration Teeth: 27T
Flange In Dia.: 35.0
Initial Torque Pre Setting (kg.m): 12.5~15.5
Super High Initial: X
Pressure Ring Cam Angle: 6060
COMPATIBILITY NOTES:
- Altezza SXE10, GXE10 with Open/Torsen type LSD.
- Mark II/Chaser/Cresta JZX90 with Open type LSD. Only AT vehicles with 1G-GE Engine.
- Mark II/Chaser/Cresta JZX100 (1JZ-GE) AT before 8/97 with Open type LSD. Tourer S Grade excluded
- Mark II/Chaser/Cresta JZX105 AT with Open type LSD.
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
Toyota Altezza GXE10 1G-FE (10/1998-04/2001)
Toyota Altezza GXE10 1G-FE (05/2001-07/2005)
Toyota Altezza SXE10 3S-GE (10/1998-04/2001)
Toyota Altezza SXE10 3S-GE (05/2001-03/2005)
Toyota Altezza Gita GXE10W 1G-FE (10/1998-07/2005)
Toyota Mark II/Chaser/Cresta JZX100 1JZ-GE (09/1996-07/1998)
Toyota Mark II/Chaser/Cresta JZX105 1JZ-GE (09/1996-07/1998)
Toyota Mark II/Chaser/Cresta JZX105 1JZ-GE (08/1998-09/2000)
Toyota Mark II/Chaser/Cresta JZX90 1JZ-GE (10/1992-08/1994)
Toyota Mark II/Chaser/Cresta JZX90 1JZ-GE (09/1994-08/1996)
Toyota Altezza GXE10 1G-FE (10/1998-04/2001)
Toyota Altezza GXE10 1G-FE (05/2001-07/2005)
Toyota Altezza SXE10 3S-GE (10/1998-04/2001)
Toyota Altezza SXE10 3S-GE (05/2001-03/2005)
Toyota Altezza Gita GXE10W 1G-FE (10/1998-07/2005)
Toyota Mark II/Chaser/Cresta JZX100 1JZ-GE (09/1996-07/1998)
Toyota Mark II/Chaser/Cresta JZX105 1JZ-GE (09/1996-07/1998)
Toyota Mark II/Chaser/Cresta JZX105 1JZ-GE (08/1998-09/2000)
Toyota Mark II/Chaser/Cresta JZX90 1JZ-GE (10/1992-08/1994)
Toyota Mark II/Chaser/Cresta JZX90 1JZ-GE (09/1994-08/1996)
