Tomei Technical Trax Advance 2 Way LSD with LSD Oil Type TXA - GA70 JZA70 GX81 JZX81 JZX90 JZX91 JZX100 JZX101 JZX110 GZ20

Brand: Tomei
Product: Technical Trax Advance 2 Way LSD with LSD Oil Type TXA - GA70 JZA70 GX81 JZX81 JZX90 JZX91 JZX100 JZX101 JZX110 GZ20
Part Num: 562042

SPECIFICATIONS:
Type: TXA
The kit Contains:
- T-Trax Advance 2 way LSD
- 2L Low Friction High Grade Oil
PCD: 160
Disc:
- Ext Dia.: 106
- No. (In Dia.): 8
- No. (Ex Dia.): 8
- Thickness: 1.7
Spring:
- No. Ex Teeth: OPT
- No. In Teeth: OPT
- No. Teeth N/A: 2
- No. Teeth N/A Strengthening: N/A
Size & No. of Ring Gear Bolts: 10-11
No. of Serration Teeth: 30T
Flange In Dia.: 35.0
Initial Torque Pre Setting (kg.m): 16.5~18.5
Super High Initial:
Pressure Ring Cam Angle: 6060

COMPATIBILITY NOTES:
- Supra GA70 before 8/90 with Open type LSD. Only vehicles with 1G-GE and 1G-GTE Engines.
- Supra GA70 after 8/90 with Torsen type LSD. Only vehicles with 1G-GE and 1G-GTE Engines.
- Supra JZA70 with Torsen type LSD.
- Mark II/Chaser/Cresta GX81 with Open type LSD. Only vehicles with 1G-GTE and 1G-GTE Engines.
- Mark II/Chaser/Cresta JZX81 with Open type LSD. Only vehicles with 1G-GE Engine.
- Mark II/Chaser/Cresta JZX90 with Torsen type LSD. Only vehicles with 1G-GTE Engine.
- Mark II/Chaser/Cresta JZX91 with Open type LSD
- Mark II/Chaser/Cresta JZX100 (1JZ-GE) AT before 8/97 with Open type LSD. Only Tourer S Grade
- Mark II/Chaser/Cresta JZX100 (1JZ-GTE) with Torsen type LSD. Only Tourer V Grade
- Mark II/Chaser/Cresta JZX101 AT before 8/97 with Open type LSD.
- Mark II JZX110 with Torsen type LSD. Only iR-V Grade vehicles with 1JZ-GTE Engine.
- Soarer GZ20 after 7/88 with Open type LSD. Only MT vehicles with 1G-GTE Engine.
