Trust Greddy Oil Cooler Kit Circuit Spec - BRZ ZD8 GR86 ZN8
122899
JPY
TRUST GREDDY
SKU: 305094
PN: 12014641This kit is a direct bolt on application designed to maintain cool engine oil temperatures. Along with increased engine oil volume Ideal size of highly efficient inner-fin design oil cooler core and strategic mounting location allow for optimum cooling properties. Depending on application the kits are available between standard and oil block relocation type layout for best clearance and accessibility. All oil blocks also come with sensor ports to properly and easily adapt most aftermarket oil pressure and temperature meters. Prolong the life of your oil and in turn your internal engine components, especially in harsh driving environments. Most blocks come with built in thermostat to regulate oil allowing engine to warm up quicker as well. Custom mounts and brackets made specifically for each application allow for a high quality durable and efficient setup. Get this and all your JDM at RHDJapan!!
Brand: Trust Greddy
Product: Oil Cooler Kit Circuit Spec- ZN6 Kouki
Part Num.: 12014641
SPECIFICATIONS:
Core Type: 10 Row L299 X H142.6 X W50
Thermostat Type: In center block
Mount Location:
- Core: Right Fender
Center Bolt Size: M20xP1.5
JAN Code: 4991995630395
COMPATIBILITY NOTES:
- Engine with center bolt size M20 x P1.5 must use Greddy oil filter OX-01, OX-02, OX-03 (3/4 -16 UNF)
- Including GReddy oil cooler sensor terminal
- Including air guide plate"
Product: Oil Cooler Kit Circuit Spec- ZN6 Kouki
Part Num.: 12014641
SPECIFICATIONS:
Core Type: 10 Row L299 X H142.6 X W50
Thermostat Type: In center block
Mount Location:
- Core: Right Fender
Center Bolt Size: M20xP1.5
JAN Code: 4991995630395
COMPATIBILITY NOTES:
- Engine with center bolt size M20 x P1.5 must use Greddy oil filter OX-01, OX-02, OX-03 (3/4 -16 UNF)
- Including GReddy oil cooler sensor terminal
- Including air guide plate"
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
Subaru BRZ ZD8 FA24 (08/2021~)
Toyota GR86 ZN8 FA24 (10/2021~)
Subaru BRZ ZD8 FA24 (08/2021~)
Toyota GR86 ZN8 FA24 (10/2021~)
