Fujitsubo Super EX Header Exhaust Manifold Basic - S14 S15 SR20DE
98759
JPY
FUJITSUBO
SKU: 51783
PN: 620-13053This item has been designed to be a direct replacement of the restrictive factory exhaust manifold and will significantly enhance exhaust flow characteristics. Enhanced diameter with smoother flowing bends coupled and superior quality materials constructed with top craftsmanship provide improved power and torque throughout the whole powerband. Get this and all your JDM at RHDJapan!!
Brand: Fujitsubo
Product: Super EX Header Exhaust Manifold Basic - S14 S15 SR20DE
Part Num: 620-13053
SPECIFICATIONS:
Kit Includes:
- 1x Super EX Header Exhaust Manifold
- 1x Gasket Packing
- 1x 60mm Dia. Ring
- 2x Bolt set for Flexible Joint
- 2x Springs for Flexible Joint
- 2x M10x40 PW Bolt Set
- 2x Collars
Material: Stainless Steel
Pipe Diameter: 42.7mm-60.5mm
Manifold Weight:
- OEM: 11.5kg
- Fujitsubo: 6.8kg
Acceleration (20km/h to 140km/h)
- OEM: 7.2 sec.
- Fujitsubo: 7.0 sec.
Maximum output
- OEM: 111.8kw (152.0ps) / 6150rpm
- Fujitsubo: 118.0kw (160.5ps) / 6280rpm
Maximum Torque
- OEM: 186.2N/m (19.0Kg/m) / 4770rpm
- Fujitsubo: 191.1N/m (19.5Kg/m) / 4730rpm
Noise Levels (dB):
OEM:
- Idling Sound: 68
- Noise Near exhaust (4800rpm): 85
- 3000rpm: 77
- 5000rpm: 87
- Response 4000rpm~6000rpm: 94
Fujitsubo:
- Idling Sound: 68
- Noise Near exhaust (4800rpm): 86
- 3000rpm: 77
- 5000rpm: 88
- Response 4000rpm~6000rpm: 98
PRODUCT NOTES:
- Performance and noise level specs are based on S15 With Fujitsubo Legalis R
COMPATIBILITY NOTES:
- Only for NA vehicles
Product: Super EX Header Exhaust Manifold Basic - S14 S15 SR20DE
Part Num: 620-13053
SPECIFICATIONS:
Kit Includes:
- 1x Super EX Header Exhaust Manifold
- 1x Gasket Packing
- 1x 60mm Dia. Ring
- 2x Bolt set for Flexible Joint
- 2x Springs for Flexible Joint
- 2x M10x40 PW Bolt Set
- 2x Collars
Material: Stainless Steel
Pipe Diameter: 42.7mm-60.5mm
Manifold Weight:
- OEM: 11.5kg
- Fujitsubo: 6.8kg
Acceleration (20km/h to 140km/h)
- OEM: 7.2 sec.
- Fujitsubo: 7.0 sec.
Maximum output
- OEM: 111.8kw (152.0ps) / 6150rpm
- Fujitsubo: 118.0kw (160.5ps) / 6280rpm
Maximum Torque
- OEM: 186.2N/m (19.0Kg/m) / 4770rpm
- Fujitsubo: 191.1N/m (19.5Kg/m) / 4730rpm
Noise Levels (dB):
OEM:
- Idling Sound: 68
- Noise Near exhaust (4800rpm): 85
- 3000rpm: 77
- 5000rpm: 87
- Response 4000rpm~6000rpm: 94
Fujitsubo:
- Idling Sound: 68
- Noise Near exhaust (4800rpm): 86
- 3000rpm: 77
- 5000rpm: 88
- Response 4000rpm~6000rpm: 98
PRODUCT NOTES:
- Performance and noise level specs are based on S15 With Fujitsubo Legalis R
COMPATIBILITY NOTES:
- Only for NA vehicles
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
Nissan Silvia S14 SR20DE (10/1993-06/1996)
Nissan Silvia S14 SR20DE (06/1996-12/1998)
Nissan Silvia S15 SR20DE (01/1999-08/2002)
Nissan Silvia S14 SR20DE (10/1993-06/1996)
Nissan Silvia S14 SR20DE (06/1996-12/1998)
Nissan Silvia S15 SR20DE (01/1999-08/2002)
