HKB Sports Boss Kit Hub Adapter - OT-135

4459 JPY
HKB SPORTS SKU: 26439 PN: OT-135
Images used may be generic. Actual product may vary.
Stock Confirmed: Standard ETA


List Price: ¥6,810

Sale Price: ¥4,459

You Save: ¥2,351


This item is for any of the Steering wheels that we have listed on our website. Be sure to note that some boss kits will eliminate the need for your airbag and turn the airbag light off as well when installed IF specifically noted in the specifications notes. When in doubt please contact first. Get this and all your JDM at RHDJapan!
Brand: HKB Sports
Product : Boss Kit Hub Adapter - OT-135
Part Number: OT-135

PRODUCT NOTES:
- MCX10: For vehicles originally equipped with airbag, Airbag Dummy Harness HKB-HT needed, sold separately.
- JZS147 equipped with airbag and cruise control: Airbag Dummy Harness HKB-HT needed, sold separately.
- VCV10 MCV20 MCV21 equipped with airbag and auto cruise switch: Airbag Dummy Harness HKB-HT needed, sold separately.
- JZS141 JZS143 JZS145 JZS147 JZS149 UZS141 UZS143 UZS145 UZS147 GS141 LS141 equipped with airbag and cruise control: Airbag Dummy Harness HKB-HT needed, sold separately. OT-268 should be applicable for some vehicles. Please ask for compatibility.
- MCV20W MCV21W MCV25W SXV20W SXV25W KCH10W KCH16W JZZ30 JZZ31 UZZ30 UZZ31 UZZ32 ACU10W ACU15W MCU10W MCU15W SXU10W SXU15W LX100 GX100 GX105 JZX100 JZX101 JZX105 equipped with airbag and cruise control: Airbag Dummy Harness HKB-HT needed, sold separately.
- UCF10 UCF11: Airbag Dummy Harness HKB-HT needed, sold separately. If turn signal does not return automatically, please use OT-184.

INSTALLATION NOTE:
- Maximum torque is just over finger tight @3.5kg. The item is composed of cast aluminum and anything more will result in damage to the boss kit. No claim on damage from installation unless video is provided from installation at provided torque spec.

COMPATIBILITY NOTES:
- MCX10: Only for Avalon equipped with cruise control 6/95~
- JZS147: Only for Aristo equipped with cruise control 10/91~7/97
- JZS147: Only for Aristo equipped with airbag and cruise control 10/91~7/97
- VCV10 MCV20 MCV21: Only for Windom equipped with auto cruise switch 9/91~
- VCV10 MCV20 MCV21: Only for Windom equipped with airbag and auto cruise switch 9/91~
- JZS141 JZS143 JZS145 JZS147 JZS149 UZS141 UZS143 UZS145 UZS147 GS141 LS141: Only for Crown equipped with cruise control 10/91~9/95
- JZS141 JZS143 JZS145 JZS147 JZS149 UZS141 UZS143 UZS145 UZS147 GS141 LS141: Only for Crown equipped with airbag and cruise control 10/91~9/95
- MCV20W MCV21W MCV25W SXV20W SXV25W: Only for Qualis equipped with airbag and cruise control 4/97~
- KCH10W KCH16W: Only for Granvia equipped with airbag and cruise control 9/95~
- GA70 GA70H JZA70 MA70: Only for Supra equipped with airbag and cruise control 8/88~5/93
- UCF10 UCF11: Only for Celsior equipped with airbag 10/89~10/94
- JZZ30 JZZ31 UZZ30 UZZ31 UZZ32: Only for Soarer equipped with cruise control equipped with or without airbags 6/91~7/96
- JZZ30 JZZ31 UZZ30 UZZ31 UZZ32: Only for Soarer equipped with cruise control equipped with or without airbags 8/96~
- ACU10W ACU15W MCU10W MCU15W SXU10W SXU15W: Only for Harrier equipped with airbag and cruise control 12/97~
- ACV40 ACV45 SV40: Only for Camry equipped with airbag and cruise control 9/94~
- LX100 GX100 GX105 JZX100 JZX101 JZX105: Only for Mark II/Chaser/Cresta equipped with airbag and cruise control 9/96~
- FJ80G FZJ80G: Only for Land Cruiser equipped with cruise control 10/89~
Toyota Aristo JZS147 2JZ-GE (08/1994-08/1997)
Toyota Aristo JZS147 2JZ-GE (10/1991-07/1994)
Toyota Aristo JZS147 2JZ-GTE (08/1994-08/1997)
Toyota Aristo JZS147 2JZ-GTE (10/1991-07/1994)
Toyota Avalon MCX10 1MZ-FE (05/1995-02/2000)
Toyota Celsior UCF10 1UZ-FE (08/1992-09/1994)
Toyota Celsior UCF10 1UZ-FE (11/1989-08/1992)
Toyota Celsior UCF11 1UZ-FE (08/1992-09/1994)
Toyota Celsior UCF11 1UZ-FE (11/1989-08/1992)
Toyota Crown GS141 1G-FE (12/1993-01/1995)
Toyota Crown JZS141 1JZ-GE (08/1993-12/1995)
Toyota Crown JZS141 1JZ-GE (10/1991-09/1992)
Toyota Crown JZS141 1JZ-GE (10/1992-07/1993)
Toyota Crown JZS143 2JZ-GE (08/1993-12/1995)
Toyota Crown JZS143 2JZ-GE (10/1991-09/1992)
Toyota Crown JZS143 2JZ-GE (10/1992-07/1993)
Toyota Crown JZS145 2JZ-GE (08/1993-12/1995)
Toyota Crown JZS145 2JZ-GE (10/1991-09/1992)
Toyota Crown JZS145 2JZ-GE (10/1992-07/1993)
Toyota Crown LS141 2L-THE (08/1993-08/1995)
Toyota Crown LS141 2L-THE (10/1991-07/1993)
Toyota Granvia KCH10W 1KZ-TE (08/1995-05/2002)
Toyota Granvia KCH16W 1KZ-TE (08/1995-05/2002)
Toyota Harrier ACU10W 2AZ-FE (01/2002-02/2003)
Toyota Harrier ACU10W 2AZ-FE (11/2000-01/2002)
Toyota Harrier MCU10W 1MZ-FE (01/2002-02/2003)
Toyota Harrier MCU10W 1MZ-FE (12/1997-01/2002)
Toyota Harrier SXU10W 3S-FE (01/2002-02/2003)
Toyota Harrier SXU10W 3S-FE (12/1997-01/2002)
Toyota Hiace Wagon KZH100G 1KZ-TE (05/1992~)
Toyota Land Cruiser FZJ80G 1FZ-FE (05/1993-01/1995)
Toyota Land Cruiser FZJ80G 1FZ-FE (05/1993-08/1996)
Toyota Mark II Qualis MCV20W 1MZ-FE (04/1997-07/1999)
Toyota Mark II Qualis MCV20W 1MZ-FE (08/1999-01/2002)
Toyota Mark II Qualis MCV21W 2MZ-FE (04/1997-07/1999)
Toyota Mark II Qualis MCV21W 2MZ-FE (08/1999-01/2002)
Toyota Mark II Qualis MCV25W 2MZ-FE (04/1997-07/1999)
Toyota Mark II Qualis MCV25W 2MZ-FE (08/1999-01/2002)
Toyota Mark II Qualis SXV20W 5S-FE (04/1997-07/1999)
Toyota Mark II Qualis SXV20W 5S-FE (08/1999-01/2002)
Toyota Mark II Qualis SXV25W 5S-FE (04/1997-07/1999)
Toyota Mark II Qualis SXV25W 5S-FE (08/1999-01/2002)
Toyota Mark II/Chaser/Cresta GX100 1G-FE (08/1998-09/2000)
Toyota Mark II/Chaser/Cresta GX100 1G-FE (09/1996-07/1998)
Toyota Mark II/Chaser/Cresta JZX100 1JZ-GE (08/1998-09/2000)
Toyota Mark II/Chaser/Cresta JZX100 1JZ-GE (09/1996-07/1998)
Toyota Mark II/Chaser/Cresta JZX100 1JZ-GTE (08/1998-09/2000)
Toyota Mark II/Chaser/Cresta JZX100 1JZ-GTE (09/1996-07/1998)
Toyota Mark II/Chaser/Cresta LX100 2L-TE (08/1998-09/2000)
Toyota Mark II/Chaser/Cresta LX100 2L-TE (09/1996-07/1998)
Toyota Soarer JZZ30 1JZ-GTE (01/1994-07/1996)
Toyota Soarer JZZ30 1JZ-GTE (06/1991-12/1993)
Toyota Soarer JZZ30 1JZ-GTE (08/1996-07/1997)
Toyota Soarer JZZ30 1JZ-GTE (08/1997-03/2001)
Toyota Soarer UZZ30 1UZ-FE (06/1991-12/1993)
Toyota Supra GA70 1G-GTE (05/1986-07/1990)
Toyota Supra GA70 1G-GTE (08/1990-04/1993)
Toyota Supra GA70H 1G-GTE (05/1986-07/1990)
Toyota Supra GA70H 1G-GTE (08/1990-04/1993)
Toyota Supra JZA70 1JZ-GTE (08/1990-04/1993)
Toyota Supra MA70 7M-GTE (02/1986-08/1988)
Toyota Supra MA70 7M-GTE (08/1988-08/1989)
Toyota Supra MA70 7M-GTE (08/1989-08/1990)
Toyota Windom MCV20 1MZ-FE (09/1996-08/2001)
Toyota Windom MCV21 2MZ-FE (08/1996-08/2001)
Toyota Windom VCV10 3VZ-FE (10/1991-08/1995)

Product Reviews

5 /5

Submit a review now and earn 20 Reward points once the review is approved.

Applies only to registered customers, may vary when logged in.

Learn more...

“ THE CUSTOMER'S VOICE ”
2/9/2021
Quality
Price
Value
RHDJapan
Great value, Perfect Fit
Great value for money, direct fit for 1994 Soarer GT-T (no airbag).
7/20/2020
Price
Value
Quality
RHDJapan
Good plug&play part for earlier A70 Supra's
Bolts straight into a 87 MA70. no modification of pins necessary.
8/2/2018
Quality
Price
Value
RHDJapan
Good Hub with nice retention of stock functionalities
I got this hub for my Chouki MA70 Supra. Fitment of the bosshub was spot on. Cruise control buttons work like a charm. Perfect solution for anyone wanting to get rid of that boat sized steering wheel.

Just one note on the wiring: You need to remove the supplied connector and replace it with the OEM connector that's on the steering wheel. I Pulled the pins using a small screwdriver and stuck them in the OEM connector. Works flawlessly. Soldering would also be an acceptable solution
4/16/2018
Price
Value
Quality
RHDJapan
This is the famous steering wheel hub for SC3/400 & Soarers that allow you to keep cruise crontrol
A direct fit on the 1992-1997 USA spec Lexus SC300 / SC400
*(I'm not sure if it works on 98-00 cars)*

Plug and play for aftermarket steering wheels and you get to keep a working cruise control

My friend also has one on his 1993 GS300. Same part number as mine.
