Tein Flex Z Coilover Suspension Kit - Civic EK2 EK3 EK4 Civic Type R EK9
114029
JPY
TEIN
SKU: 336348
PN: VSH00-C1SS3The Flex Z lineup has been developed as a full-spec street based coilover suspension kit. Along with full length adjustability and a wide range of damper force settings. Twin-tube design provides longer stroke for enhanced comfort, upper mounts provide further accurate operation. High spec suspension developed at great cost performance and low-cost maintenance. Handling refinement can control can further be leveled up with in cabin damper settings through EDFC system. Get this and all your JDM at RHDJapan!!
Brand: Tein
Product: Flex Z Coilover Suspension Kit - VSH00-C1SS3
Part Number: VSH00-C1SS3
SPECIFICATIONS:
Series: Flex Z
Damping force adjustment:
- Front: 16-level
- Rear: 16-level
Mounts:
- Front: Reinforced Rubber
- Rear: Reinforced Rubber
Ride Height Adjustment:
- Front: Full Length Adjustment
- Rear: Full Length Adjustment
Spring Rate N/mm (kgf/mm):
- Front: 98.1 (10.0)
- Rear: 58.8 (6.0)
Free Length (mm):
- Front: 175
- Rear: 175
Inner Diameter (mm):
- Front: Φ65
- Rear: Φ65
PRODUCT NOTES:
- Civic EK2 (09/1995~08/2000):
Stock Height Difference (mm):
- Front: -45
- Rear: -50
Maximum adjustment range (mm):
- Front: -124 to -11
- Rear: -113 to -15
Recommended adjustment height range (mm):
- Front: -55 to -35
- Rear: -60 to -40
- Civic EK3 (09/1995~08/2000):
Stock Height Difference (mm):
- Front: -45
- Rear: -50
Maximum adjustment range (mm):
- Front: -124 to -11
- Rear: -113 to -15
Recommended adjustment height range (mm):
- Front: -55 to -35
- Rear: -60 to -40
- Civic EK4 (09/1995~08/2000):
Stock Height Difference (mm):
- Front: -45
- Rear: -50
Maximum adjustment range (mm):
- Front: -89 to +0
- Rear: -113 to -10
Recommended adjustment height range (mm):
- Front: -55 to -35
- Rear: -60 to -40
- Civic Type R EK9 (08/1997~08/2000):
Stock Height Difference (mm):
- Front: -30
- Rear: -35
Maximum adjustment range (mm):
- Front: -109 to +4
- Rear: -98 to +0
Recommended adjustment height range (mm):
- Front: -40 to -20
- Rear: -45 to -25
- Electronic Damping Force Controller Set-up: Controller (EDFC5 PN: EDK04-R6655 or Active Pro PN: EDK04-Q0349) + Motor Kit (PN: EDK05-12120) [Optional GPS Kit PN: EDK07-P8022]
COMPATIBILITY NOTES:
- Civic EK2 09/1995~08/2000: Compared To The Original Car's Tall Unstable Feel And Slow Movement, Body Roll Is Reduced With The Use Of Stiffer Rate Springs And Turn-in Ability At Corners Is Improved By Optimizing Damping Force, Considering Ride Comfort At Low To Mid Speed On Streets.
- Civic EK3 09/1995~08/2000: Compared To The Original Car's Tall Unstable Feel And Slow Movement, Body Roll Is Reduced With The Use Of Stiffer Rate Springs And Turn-in Ability At Corners Is Improved By Optimizing Damping Force, Considering Ride Comfort At Low To Mid Speed On Streets.
- Civic EK4 09/1995~08/2000: Compared To The Original Car's Tall Unstable Feel And Slow Movement, Body Roll Is Reduced With The Use Of Stiffer Rate Springs And Turn-in Ability At Corners Is Improved By Optimizing Damping Force, Considering Ride Comfort At Low To Mid Speed On Streets.
- Civic Type R EK9 08/1997~08/2000: Compared To The Original Car's Tall Unstable Feel And Slow Movement, Body Roll Is Reduced With The Use Of Stiffer Rate Springs And Turn-in Ability At Corners Is Improved By Optimizing Damping Force, Considering Ride Comfort At Low To Mid Speed On Streets.
Product: Flex Z Coilover Suspension Kit - VSH00-C1SS3
Part Number: VSH00-C1SS3
SPECIFICATIONS:
Series: Flex Z
Damping force adjustment:
- Front: 16-level
- Rear: 16-level
Mounts:
- Front: Reinforced Rubber
- Rear: Reinforced Rubber
Ride Height Adjustment:
- Front: Full Length Adjustment
- Rear: Full Length Adjustment
Spring Rate N/mm (kgf/mm):
- Front: 98.1 (10.0)
- Rear: 58.8 (6.0)
Free Length (mm):
- Front: 175
- Rear: 175
Inner Diameter (mm):
- Front: Φ65
- Rear: Φ65
PRODUCT NOTES:
- Civic EK2 (09/1995~08/2000):
Stock Height Difference (mm):
- Front: -45
- Rear: -50
Maximum adjustment range (mm):
- Front: -124 to -11
- Rear: -113 to -15
Recommended adjustment height range (mm):
- Front: -55 to -35
- Rear: -60 to -40
- Civic EK3 (09/1995~08/2000):
Stock Height Difference (mm):
- Front: -45
- Rear: -50
Maximum adjustment range (mm):
- Front: -124 to -11
- Rear: -113 to -15
Recommended adjustment height range (mm):
- Front: -55 to -35
- Rear: -60 to -40
- Civic EK4 (09/1995~08/2000):
Stock Height Difference (mm):
- Front: -45
- Rear: -50
Maximum adjustment range (mm):
- Front: -89 to +0
- Rear: -113 to -10
Recommended adjustment height range (mm):
- Front: -55 to -35
- Rear: -60 to -40
- Civic Type R EK9 (08/1997~08/2000):
Stock Height Difference (mm):
- Front: -30
- Rear: -35
Maximum adjustment range (mm):
- Front: -109 to +4
- Rear: -98 to +0
Recommended adjustment height range (mm):
- Front: -40 to -20
- Rear: -45 to -25
- Electronic Damping Force Controller Set-up: Controller (EDFC5 PN: EDK04-R6655 or Active Pro PN: EDK04-Q0349) + Motor Kit (PN: EDK05-12120) [Optional GPS Kit PN: EDK07-P8022]
COMPATIBILITY NOTES:
- Civic EK2 09/1995~08/2000: Compared To The Original Car's Tall Unstable Feel And Slow Movement, Body Roll Is Reduced With The Use Of Stiffer Rate Springs And Turn-in Ability At Corners Is Improved By Optimizing Damping Force, Considering Ride Comfort At Low To Mid Speed On Streets.
- Civic EK3 09/1995~08/2000: Compared To The Original Car's Tall Unstable Feel And Slow Movement, Body Roll Is Reduced With The Use Of Stiffer Rate Springs And Turn-in Ability At Corners Is Improved By Optimizing Damping Force, Considering Ride Comfort At Low To Mid Speed On Streets.
- Civic EK4 09/1995~08/2000: Compared To The Original Car's Tall Unstable Feel And Slow Movement, Body Roll Is Reduced With The Use Of Stiffer Rate Springs And Turn-in Ability At Corners Is Improved By Optimizing Damping Force, Considering Ride Comfort At Low To Mid Speed On Streets.
- Civic Type R EK9 08/1997~08/2000: Compared To The Original Car's Tall Unstable Feel And Slow Movement, Body Roll Is Reduced With The Use Of Stiffer Rate Springs And Turn-in Ability At Corners Is Improved By Optimizing Damping Force, Considering Ride Comfort At Low To Mid Speed On Streets.
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
Honda Civic EK2 D13B (09/1995-09/1998)
Honda Civic EK2 D13B (09/1998-08/2000)
Honda Civic EK3 D15B (09/1995-09/1998)
Honda Civic EK3 D15B (09/1998-08/2000)
Honda Civic EK4 B16A (09/1995-09/1998)
Honda Civic EK4 B16A (09/1998-08/2000)
Honda Civic Type-R EK9 B16B (08/1997-09/1998)
Honda Civic Type-R EK9 B16B (09/1998-08/2000)
Honda Civic EK2 D13B (09/1995-09/1998)
Honda Civic EK2 D13B (09/1998-08/2000)
Honda Civic EK3 D15B (09/1995-09/1998)
Honda Civic EK3 D15B (09/1998-08/2000)
Honda Civic EK4 B16A (09/1995-09/1998)
Honda Civic EK4 B16A (09/1998-08/2000)
Honda Civic Type-R EK9 B16B (08/1997-09/1998)
Honda Civic Type-R EK9 B16B (09/1998-08/2000)
