Tomei Technical Trax Advance 2 Way LSD Type CXA - HCR32 ENR33 ECR33 S14 Z32 Y32 NA31 GC34 GNC34
125089
JPY
TOMEI
SKU: 97810
PN: 562017_2397464This is the most effective LSD unit available and has the best overall advantage in comparison with the other aftermarket products available today. Amazing penetrating angles at the time of Drift, with such persistence in the accuracy of line taking and all aspects of cornering, the T-TRAX ADVANCE shows amazing efficiency with the aggressive cam angles which is optimum for drifting. The friction clutch discs also have a larger surface area and, with the use of the coil spring discs and the high setting of initial torque, it is raised higher than any other brands in the market today.
Get this and all your JDM at RHDJapan!!
Get this and all your JDM at RHDJapan!!
Brand: Tomei
Product: Technical Trax Advance 2 Way LSD Type CXA - HCR32 ENR33 ECR33 S14 Z32 Y32 NA31 GC34 GNC34
Part Number: 562017_2397464
SPECIFICATIONS:
Type: CXA
Included:
- T-Trax Advance 2 way LSD
- 1x Carrier Cover Gaskets
- 2x Bearings
- 2x Oil Seals
SPECIFICATIONS:
Model CXA:
- PCD: 150
- Disc:
-- Ext Dia.: 106
-- No. (In Dia.): 10
-- No. (Ex Dia.): 10
-- Thickness: 1.7
- Spring:
-- No. Ex Teeth: OPT
-- No. In Teeth: OPT
-- No. Teeth N/A: 2
-- No. Teeth N/A Strengthening: N/A
- Size & No. of Ring Gear Bolts: 10-13
- No. of Serration Teeth: 29T
- Flange In Dia.: 32.0
- Initial Torque Pre Setting (kg.m): 16.5~18.5
- Super High Initial:
- Pressure Ring Cam Angle: 6060
COMPATIBILITY NOTES:
Only for The Following Vehicles mounting OEM Viscous type LSD:
- Skyline HCR32
- Skyline ENR33 before 12/96
- Skyline ECR33 (except active LSD models).
- Silvia S14 Turbo MT before 12/96
- Silvia S14 Turbo AT after 12/96
- 180SX RPS13 Turbo after 12/96
- Fairlady Z Z32 NA
- Cedric/Gloria Y32 Only AT models with VG30DE engine
- Cefiro LNA31 Only 4WD AT models.
- Laurel GC34 Turbo before 12/96, Only AT models.
- Laurel GNC34 before 12/96, Only 4WD AT models.
Product: Technical Trax Advance 2 Way LSD Type CXA - HCR32 ENR33 ECR33 S14 Z32 Y32 NA31 GC34 GNC34
Part Number: 562017_2397464
SPECIFICATIONS:
Type: CXA
Included:
- T-Trax Advance 2 way LSD
- 1x Carrier Cover Gaskets
- 2x Bearings
- 2x Oil Seals
SPECIFICATIONS:
Model CXA:
- PCD: 150
- Disc:
-- Ext Dia.: 106
-- No. (In Dia.): 10
-- No. (Ex Dia.): 10
-- Thickness: 1.7
- Spring:
-- No. Ex Teeth: OPT
-- No. In Teeth: OPT
-- No. Teeth N/A: 2
-- No. Teeth N/A Strengthening: N/A
- Size & No. of Ring Gear Bolts: 10-13
- No. of Serration Teeth: 29T
- Flange In Dia.: 32.0
- Initial Torque Pre Setting (kg.m): 16.5~18.5
- Super High Initial:
- Pressure Ring Cam Angle: 6060
COMPATIBILITY NOTES:
Only for The Following Vehicles mounting OEM Viscous type LSD:
- Skyline HCR32
- Skyline ENR33 before 12/96
- Skyline ECR33 (except active LSD models).
- Silvia S14 Turbo MT before 12/96
- Silvia S14 Turbo AT after 12/96
- 180SX RPS13 Turbo after 12/96
- Fairlady Z Z32 NA
- Cedric/Gloria Y32 Only AT models with VG30DE engine
- Cefiro LNA31 Only 4WD AT models.
- Laurel GC34 Turbo before 12/96, Only AT models.
- Laurel GNC34 before 12/96, Only 4WD AT models.
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
