Tomei Technical Trax Advance 2 Way LSD Type EA - BNR32 BCNR33 BNR34 R34 S15 Y33 C35

Brand: Tomei
Product: Technical Trax Advance 2 Way LSD Type EA - BNR32 BCNR33 BNR34 R34 S15 Y33 C35
Part Number: 562019_120321

SPECIFICATIONS:
Included:
- T-Trax Advance 2 way LSD
- 1x Carrier Cover Gaskets
- 2x Bearings
- 2x Oil Seals

SPECIFICATIONS:
- PCD: 150
- Disc:
-- Ext Dia.: 106
-- No. (In Dia.): 10
-- No. (Ex Dia.): 10
-- Thickness: 1.7
- Spring:
-- No. Ex Teeth: OPT
-- No. In Teeth: OPT
-- No. Teeth N/A: 2
-- No. Teeth N/A Strengthening: N/A
- Size & No. of Ring Gear Bolts: 10-13
- No. of Serration Teeth: 30T
- Flange In Dia.: 32.0
- Initial Torque Pre Setting (kg.m): 16.5~18.5
- Super High Initial:
- Pressure Ring Cam Angle: 6060

COMPATIBILITY NOTES:
- Skyline BNR32 with Mechanical type LSD, on kouki models (after 2/93) exchange of the Part Numbers 38220-05U10 38220-05U11 is necessary.
- Skyline BCNR33, BNR34 with Viscous type LSD (except active LSD models), exchange of the Part Numbers 38220-05U10 38220-05U11 is necessary.
- Skyline HR34, ER34Normally Aspirated with Open type LSD
- Skyline ER34 Turbo with Helical type LSD after 8/99, Only MT Vehicles.
- Silvia S15 NA with Open type LSD or with Helical type LSD.
- Silvia S15 Turbo with Helical type LSD, Only MT Vehicles.
- Cedric/Gloria Y33 with Open type LSD, Only AT models with VQ30DE and VQ30DET engines
- Laurel GC35, SC35, GNC35, HC35 with Open type LSD, Only AT models.
