Tomei Technical Trax Advance 2 Way LSD Type IA - HR32 ER32 HR33 ER33 S13 PS13 S14 RPS13 A31 HC33 HC34 GC34 SC34

Brand: Tomei
Product: Technical Trax Advance 2 Way LSD Type IA - HR32 ER32 HR33 ER33 S13 PS13 S14 RPS13 A31 HC33 HC34 GC34 SC34
Part Number: 562021_2397466

SPECIFICATIONS:
Type: IA
Included:
- T-Trax Advance 2 way LSD
- 1x Carrier Cover Gaskets (Types HA and F Exclude)
- 2x Bearings
- 2x Oil Seals

SPECIFICATIONS:
- PCD: 150
- Disc:
-- Ext Dia.: 106
-- No. (In Dia.): 8
-- No. (Ex Dia.): 8
-- Thickness: 1.7
- Spring:
-- No. Ex Teeth: OPT
-- No. In Teeth: OPT
-- No. Teeth N/A: 2
-- No. Teeth N/A Strengthening: N/A
- Size & No. of Ring Gear Bolts: 10-12
- No. of Serration Teeth: 29T
- Flange In Dia.: 32.0
- Initial Torque Pre Setting (kg.m): 16.5~18.5
- Super High Initial:
- Pressure Ring Cam Angle: 6060

COMPATIBILITY NOTES:
Only for The Following Vehicles mounting OEM Open type LSD:
- Skyline HR32, ER32
- Skyline HR33, ER33
- Silvia S13 NA. Not for Vehicles equipped with R180 Differential.
- Silvia PS13 NA with ABS. Not for Vehicles equipped with R180 Differential.
- Silvia S14 NA with ABS. Not for Vehicles equipped with R180 Differential.
- 180SX RPS13 NA.
- Cefiro A31 (RB20E) with ABS. Not for Vehicles equipped with R180 Differential.
- Cefiro A31 (RB20DE).
- Cefiro A31 (RB25DE), Only AT models.
- Laurel HC33 (RB20E) AT. Not for Vehicles equipped with R180 Differential.
- Laurel HC33 (RB20E) MT with ABS. Not for Vehicles equipped with R180 Differential.
- Laurel HC34 (RB20E) AT with ABS. Not for Vehicles equipped with R180 Differential.
- Laurel GC34 NA, Only AT models.
- Laurel SC34.
