Tomei Technical Trax Advance 2 Way LSD with LSD Oil Type TB - JZA80 JZZ30 JZZ31 UZZ31 UZZ40 UZS143 JZS147 JZS160 JZS161
135439
JPY
TOMEI
SKU: 146275
PN: 562027This is the most effective LSD unit available and has the best overall advantage in comparison with the other aftermarket products available today. Amazing penetrating angles at the time of Drift, with such persistence in the accuracy of line taking and all aspects of cornering, the T-TRAX ADVANCE shows amazing efficiency with the aggressive cam angles which is optimum for drifting. The friction clutch discs also have a larger surface area and, with the use of the coil spring discs and the high setting of initial torque, it is raised higher than any other brands in the market today.
Get this and all your JDM at RHDJapan!!
Get this and all your JDM at RHDJapan!!
Brand: Tomei
Product: Technical Trax Advance 2 Way LSD with LSD Oil - JZA80 JZZ30 JZZ31 UZZ31 UZZ40 UZS143 JZS147 JZS160 JZS161
Part Num: 562027
SPECIFICATIONS:
Type: TB
The kit Contains:
- T-Trax Advance 2 way LSD
- 2L Low Friction High Grade Oil
PCD: 150
Disc:
- Ext Dia.: 106
- No. (In Dia.): 4
- No. (Ex Dia.): 4
- Thickness: 1.7
Spring:
- No. Ex Teeth: 2
- No. In Teeth: 2
- No. Teeth N/A: OPT
- No. Teeth N/A Strengthening: N/A
Size & No. of Ring Gear Bolts: 10-11
No. of Serration Teeth: 30T
Flange In Dia.: 35.0
Initial Torque Pre Setting (kg.m): 12.0~14.0
Super High Initial: X
Pressure Ring Cam Angle: 6060
COMPATIBILITY NOTES:
- Supra JZA80 (2JZ-GE) with Open/Torsen type LSD. Torsen equipped models before 6/96 will require the side shafts to be exchanged (both left & right part numbers 41309-240202).
- Supra JZA80 (2JZ-GTE) before 6/96 with Open/Torsen type LSD. Torsen equipped models will require the side shafts to be exchanged (both left & right part numbers 41309-240202). No MT Vehicles
- Supra JZA80 (2JZ-GTE) after 6/96 with Open/Torsen type LSD. Only 6 Speed vehicles with 30 Spline.
- Soarer JZZ30, JZZ31, UZZ31 with Open/Torsen type LSD. Torsen equipped models before 8/96 will require the side shafts to be exchanged (both left & right part numbers 41309-240202).
- Soarer UZZ40 AT with Open type LSD. Only vehicles before 5/03.
- Aristo UZS143 AT with Open/Torsen type LSD. Torsen equipped models before 8/96 will require the side shafts to be exchanged (both left & right part numbers 41309-240202). Only 4WD vehicles.
- Aristo JZS147 (2JZ-GE) AT with Open type LSD.
- Aristo JZS147 (2JZ-GTE) AT with Open/Torsen type LSD. Torsen equipped models before 8/96 will require the side shafts to be exchanged (both left & right part numbers 41309-240202).
- Aristo JZS160, JZS161 AT with Open/Torsen type LSD. Torsen equipped models before 8/96 will require the side shafts to be exchanged (both left & right part numbers 41309-240202).
Product: Technical Trax Advance 2 Way LSD with LSD Oil - JZA80 JZZ30 JZZ31 UZZ31 UZZ40 UZS143 JZS147 JZS160 JZS161
Part Num: 562027
SPECIFICATIONS:
Type: TB
The kit Contains:
- T-Trax Advance 2 way LSD
- 2L Low Friction High Grade Oil
PCD: 150
Disc:
- Ext Dia.: 106
- No. (In Dia.): 4
- No. (Ex Dia.): 4
- Thickness: 1.7
Spring:
- No. Ex Teeth: 2
- No. In Teeth: 2
- No. Teeth N/A: OPT
- No. Teeth N/A Strengthening: N/A
Size & No. of Ring Gear Bolts: 10-11
No. of Serration Teeth: 30T
Flange In Dia.: 35.0
Initial Torque Pre Setting (kg.m): 12.0~14.0
Super High Initial: X
Pressure Ring Cam Angle: 6060
COMPATIBILITY NOTES:
- Supra JZA80 (2JZ-GE) with Open/Torsen type LSD. Torsen equipped models before 6/96 will require the side shafts to be exchanged (both left & right part numbers 41309-240202).
- Supra JZA80 (2JZ-GTE) before 6/96 with Open/Torsen type LSD. Torsen equipped models will require the side shafts to be exchanged (both left & right part numbers 41309-240202). No MT Vehicles
- Supra JZA80 (2JZ-GTE) after 6/96 with Open/Torsen type LSD. Only 6 Speed vehicles with 30 Spline.
- Soarer JZZ30, JZZ31, UZZ31 with Open/Torsen type LSD. Torsen equipped models before 8/96 will require the side shafts to be exchanged (both left & right part numbers 41309-240202).
- Soarer UZZ40 AT with Open type LSD. Only vehicles before 5/03.
- Aristo UZS143 AT with Open/Torsen type LSD. Torsen equipped models before 8/96 will require the side shafts to be exchanged (both left & right part numbers 41309-240202). Only 4WD vehicles.
- Aristo JZS147 (2JZ-GE) AT with Open type LSD.
- Aristo JZS147 (2JZ-GTE) AT with Open/Torsen type LSD. Torsen equipped models before 8/96 will require the side shafts to be exchanged (both left & right part numbers 41309-240202).
- Aristo JZS160, JZS161 AT with Open/Torsen type LSD. Torsen equipped models before 8/96 will require the side shafts to be exchanged (both left & right part numbers 41309-240202).
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
