Blitz makes one of the highest performing and durable parts on the market and the Damper ZZ-R is the latest addition to their suspension parts catalog. The ZZ-Rs are mono cylinder dampers with 32 stage adjustment, are made from high strength materials and feature an outstanding finish in anodized red and matte black.
Get this and all your JDM at RHDJapan!!
Get this and all your JDM at RHDJapan!!
Brand: Blitz
Product: Damper ZZ-R Coilover Suspension - A200A A200S
Part Num: 92559
SPECIFICATIONS:
Materials:
- Springs: Special high-tension Steel (SAE9245)
- Cylinder Case: High-strength Steel (STKM13C)
Upper Mount Configuration:
- Front: OEM
- Rear: OEM
Spring Spec.:
- Spring Rate (kgf.mm):
-- Front: 4.0
-- Rear: 3.0
- Free Length (mm):
-- Front: 220
-- Rear: 220
Height adjustment range:
- Front: -70 ~ 0
- Rear: -70 ~ -35
FEATURES:
- Single Cylinder Type
- 32 stage adjustment method
- Practical use for street circuit and wide range of events
- Designed with large diameter piston at 44mm (some vehicles)
- Forged aluminum upper mount
- Forged aluminum sheet for reduced weight and increased durability and strength
- Rigid bracket coated with special pain to achieve durability
- Aluminum bracket coated in black anodized paint to improve corrosion resistance
COMPATIBILITY NOTES:
- Only for 2WD vehicles.
Product: Damper ZZ-R Coilover Suspension - A200A A200S
Part Num: 92559
SPECIFICATIONS:
Materials:
- Springs: Special high-tension Steel (SAE9245)
- Cylinder Case: High-strength Steel (STKM13C)
Upper Mount Configuration:
- Front: OEM
- Rear: OEM
Spring Spec.:
- Spring Rate (kgf.mm):
-- Front: 4.0
-- Rear: 3.0
- Free Length (mm):
-- Front: 220
-- Rear: 220
Height adjustment range:
- Front: -70 ~ 0
- Rear: -70 ~ -35
FEATURES:
- Single Cylinder Type
- 32 stage adjustment method
- Practical use for street circuit and wide range of events
- Designed with large diameter piston at 44mm (some vehicles)
- Forged aluminum upper mount
- Forged aluminum sheet for reduced weight and increased durability and strength
- Rigid bracket coated with special pain to achieve durability
- Aluminum bracket coated in black anodized paint to improve corrosion resistance
COMPATIBILITY NOTES:
- Only for 2WD vehicles.
Compatibility is from maker for JDM cars only. We don't guarantee fitment. Always do your own research before purchase. After-sale support does not include installation support.
Daihatsu Rocky A200S 1KR-VET (11/2019-11/2021)
Toyota Raize A200A 1KR-VET (11/2019-11/2021)
Daihatsu Rocky A200S 1KR-VET (11/2019-11/2021)
Toyota Raize A200A 1KR-VET (11/2019-11/2021)
