HKS V Camshaft Intake & Exhaust Set - ZC6 ZN6 Applied Model B~H

Brand: HKS
Product: V Camshaft Intake & Exhaust Set - ZC6 ZN6 Applied Model B~H
Part Num: 22002-AT006

SPECIFICATIONS:
Set Includes:
- 2x Intake and Exhaust Camshaft
Duration: 260 IN, 266 EX
Lift (mm): 11.70 both
Valve Timing: 82~150 IN, 81~135 EX
VVT Variable Timing: 68 IN, 54 EX

PRODUCT NOTES:
- To keep adequate valve clearance, use with HKS piston kit
- Settings of fuel, ignition, valve timing are required.
- Check if the valve clearance is adequate during installation
- Always refer to the factory service manual or a professional for installation.

FEATURES:
- High acceleration and pick-up camshafts were completed by meticulous analysis of the stock rocker structure.
- Cam lobe for the direct injection pump is available so the camshaft can be used the same way as the stock.
- The valve timing is the knock pin is matched to stock cam, so, there is no need for complicated installation.
- Since the stock valve piston clearance is narrow, this camshaft kit was developed to be used with the capacity upgrade kit, and the piston recess was redesigned to enable a 0.7mm lift increase without replacing the springs.

COMPATIBILITY NOTES:
-Capacity up kits: (21004-AT002/21004-AT003)
-Only Applied Models B~H
